Retekess TT006 Portable 64 Slot Charge Case Storage Box for T130 TT106 receiver
It is made of the aluminum alloy
You can put down all the accessories. It is very convenient for you.
64 ports Charging case for Retekess T130 T131 TT106 tour guide system
it is a durable and fire-resistant Portable design, you can take it anywhere.
Bulk order Inquiry
OverView
Retekess Silver TT006 Portable 64 Slot Charge Case Storage Box for T130 T131 TT106 Wireless Tour Guide System
It is made of aluminum alloy, it is durable and fire-resistant
Portable design, you can take it anywhere.
You can put down all the accessories. It is very convenient for you.
This is 64 ports charging case, we also have 30 ports charging case, if you need it, pls feel free to contact us.
This charging case is very useful for tour guides, translators, you can take it with you with all your tour guide systems and translation devices, and you can put all the accessories in it. It can also save a lot of time for you. Giving the products to your customers one by one is very easy, don't worry about the wires
Spec
Specification:
| Input properties | Input voltage | AC90-250VAC, 47~63Hz |
| AC input current | 1.5A/230VAC | |
| Power supply efficiency | 76% | |
| Inrush current | cold start current 36A/230V | |
| Leakage current | <2mA/240VAC | |
| Output characteristics | DC output voltage | 5V |
| Output voltage tolerance | ±1% | |
| Output current range | 0~7A (single power supply) | |
| Output power | 140W | |
| Ripple and noise | 80mVp-p | |
| Protection characteristics | Overload protection | Overload protection starts at 115%~135% of rated output power |
| Protection mode: hiccup mode, automatically recovers after abnormal load conditions are removed | ||
| Overvoltage protection | 145%~170% of rated output voltage | |
| Protection mode: hiccup mode, automatically recovers after abnormal conditions are removed | ||
| Over-temperature protection | When the internal contact temperature of the transistor exceeds 150°C, over-temperature protection is activated. | |
| Protection mode: hiccup mode, automatically resumes when the temperature returns to normal | ||
| working environment | Working temperature and humidity | -10℃～+60℃; 20%～90%RH (please refer to the load derating curve) |
| Safety Voltage | resistance | Between input and output: 1.5KVAC Input and ground: 1.5KVAC Output and ground: 0.5KVAC |
| Insulation resistance | between input and output: input and ground, output and ground: 100M Ohms/500VDC | |
| Size | 575 x290 x 140mm | |
| Weight | 4320g | |
| Remarks: 1. Unless otherwise specified, all parameters are measured under the conditions of 230VAC voltage input, rated load and 25℃. 2. The ripple and noise voltages are measured on a 20MHz bandwidth oscilloscope with 0.1u and 47u capacitors added to the end of a 12-inch twisted pair. 3. Tolerance is the sum of voltage setting error, voltage regulation rate and current regulation rate. |
||
Package Includes:
1 x 64 slot charging case
1 x Charging cable
